Now Available: Addition of Mobile Mapping Capability via Vehicle Mount and Integration
GeoCue now offers customers a flexible TrueView lineup that enables users to collect data from the air, or via mobile mapping rig. Setup is easy and intuitive, giving users the ability to complement their aerial data with data captured from a ground vehicle. Three mobile mapping packages including fully integrated hardware and software are available to meet your project needs.
 TrueView 680/680LR360 LiDAR Sensor |  TrueView 655/660Survey Grade Sensor |  TrueView 6253D Imaging System |
|---|---|---|
 TrueView 535UPDATED! All-Purpose Sensor |  TrueView 515MOST POPULAR! All-Purpose Sensor |
Basic
Mobile Mapping Kit
-
-
Vehicle Mount (Fixed roof & cabling kit)
-
Land GNSS Antenna
-
POSPac MMS (specific for Mobile Mapping)
Pro
Mobile Mapping Kit
-
-
Vehicle Mount (Fixed roof & cabling kit)
-
Land GNSS Antenna
-
POSPac MMS (specific for Mobile Mapping)
-
DMI (connected to vehicle’s rear wheel) with cabling + SW module
​​
Optional
-
Swivel plate (rotating plate)
-
360 degree Camera Integration Mounting kit: Mast, Dedicated SW (Colorization and visualization) and cabling
-
360 degree Flir LadyBug Camera
Expert
Mobile Mapping Kit
Compatible only with the TrueView 600 Series
-
Vehicle Mount (Fixed roof & cabling kit)
-
Land GNSS Antenna
-
POSPac MMS (specific for Mobile Mapping)
-
DMI (connected to vehicle’s rear wheel) with cabling + SW module
-
Additional Expert Software Modules
​​
Optional
-
360 degree Camera Integration Mounting kit: Mast, Dedicated SW (Colorization and visualization) and cabling
-
360 degree Flir LadyBug Camera
How These Options Improve Data Collection and Capability
DMI
The DMI is connected to the wheel of the vehicle and connected to the board of the mobile mapping system.
​
When driving in cities, customers face GNSS masks due to onstructions such as buildings, tunnels,etc.
​
The DMI compensates by providing information such as distance.
​
The DMI is very specific to the wheel used. The customer will be required to provide information before purchasing the correct DMI.
Teledyne Flir Ladybug Camera
The 360° camera allows you to collect imagery as the Lidar will only generate a point cloud.
​
The 360° camera will be installed on a fixed mast and will be delivered with visualisation software.
​
The 360° camera will also be used to colorize the point cloud.
Swivel plate (rotating plate)
Our LiDAR standard mount has a fixed position on the vehicle.
To collect as much data as possible, the customer may need to make several paths using different angles to collect data.
​
This is why we have designed and offer a specific plate giving the possibility to rotate the scanner 0°-15°-30°.
​
The customer will make several paths using different angles and will therefore collect more data.
Manage your mobile mapping project in real time, using the dedicated application
Easily configure your equipment when switching from drone to mobile mapping data collection.
